With light weight, small volume, convenient to move, ET series standard vibration table is widely used in the acceleration sensor calibration; vibration test, fatigue test and mechanical impedance test of micro parts; at the same time, the ET series can also be used for teaching, scientific research and laboratory.
Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability
Load center airbag with high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation
Airbag shock isolation device for vibration platform without the
need ofadditional foundation, perfect reproduction of vibrationa wave and reduce vibration transmittance
Quickself-diagnosis with safety interlock, high safety reliability
Rugged suspension system and linear motion guiding, strong carrying capacity, good guiding functions, high stability
Load center airbag with high static stiffness and low dynamic stiffness, strong carrying capacity, perfect performance on amplitude variation
Airbag shock isolation device for vibration platform without the
need ofadditional foundation, perfect reproduction of vibrationa wave and reduce vibration transmittance
System Model | ET55 | ET30 | ET10 |
Frequency Range(Hz) | 5-5500 | 5-6500 | 5-10000 |
Max Sine Force kg.f(N) | 55(550) | 30(300) | 10(100) |
Max Displacement(mm p-p) | 20 | 12 | 10 |
Max Acceleration(g) | 30 | 35 | 35 |
Max. Velocity(m/s) | 1.3 | 1.5 | 1.5 |
Max. Load | 20 | 1 | 1 |
Armature Diameter | 1.8 | 0.45 | 0.3 |
We also provide optional devices to fit your specific requirement better:
